Ultra Slim Video Wall P1.25 - LSCB

Key Features

  • Pixel Pitch: 1.25mm
  • Brightness: 800cd/m²
  • Ultra Slim Depth
  • EMC Class B, BS 476 Part7 Class 1

If you're looking for an ultra slim video wall with a pixel pitch of P1.25 for your business, you're likely interested in a high-resolution display solution. P1.25 refers to the pixel pitch, which is the distance between the centers of adjacent pixels. A smaller pixel pitch, such as P1.25, indicates a higher pixel density and allows for sharper and more detailed images.

Video walls are used in various industries for advertising, information display, entertainment, and more. An ultra slim video wall can provide a seamless and immersive visual experience for your business, whether it's for showcasing products, engaging customers, or enhancing your brand presence.


OPTICAL SPECIFICATIONS
Max Brightness (After Calibration, Nit) : 800
Color Temperature (K) : 3,200~9,300
Brightness Uniformity : 0.97
Visual Viewing Angle (Vertical) : 160
Visual Viewing Angle (Horizontal) : 160
Color Uniformity : ±0.003Cx,Cy
Contrast Ratio : 5,000:1
Processing Depth (bit) : 14 (HDR10, HDR10 Pro)

PHYSICAL PARAMETERS
Pixel Configuration : Single SMD
Pixel Pitch (mm) : 1.25
Module Resolution (W X H) : 240 × 135
Module Dimensions (W X H, Mm) : 300 × 168.75
Cabinet Resolution (W × H) : 480x270
Cabinet Dimensions (W × H × D) : 600x337.5x34
Weight Per Square Meter (kg/m²) : 26.17
Cabinet Material : Die-casting Aluminum
Service Access : Front

OPERATION SPECIFICATIONS
LED Lifetime (Half Brightness) : 100,000
Operating Temperature(℃) : -10℃ to +45℃
Operating Humidity : 0~80%RH
IP Rating Front : IP30
IP Rating Rear : IP30
