An ultra slim video wall with a pixel pitch of P1.56 refers to a display solution with a relatively high pixel density. The pixel pitch of P1.56 indicates that the distance between the centers of adjacent pixels is 1.56 millimeters. With this pixel pitch, the video wall can provide clear and detailed visuals, making it suitable for a wide range of applications.
The ultra slim design of the video wall means that the bezels (the borders between individual display panels) are minimized, allowing for a more seamless and immersive viewing experience. This can be particularly useful in settings where you want to create a large video display that appears as a single, cohesive image.
P1.56 video walls are commonly used in various business environments, such as retail stores, control rooms, exhibition halls, conference rooms, and digital signage installations. They can be used to showcase products, deliver dynamic advertising content, provide information of your business.
OPTICAL SPECIFICATIONS
Color Temperature (K) : 3,200~9,300
Visual Viewing Angle (Horizontal) : 160
Visual Viewing Angle (Vertical) : 160
Brightness Uniformity : 0.97
Color Uniformity : ±0.003Cx,Cy
Contrast Ratio : 5,000:1
Processing Depth (bit) : Processing Depth (bit)
PHYSICAL PARAMETERS
Pixel Pitch (mm) : 1.56
Module Resolution (W X H) : 192 × 108
Module Dimensions (W X H, Mm) : 300 × 168.75
Weight Per Module (kg) : 0.34
No. Of Modules Per Cabinet (W × H) : 2 × 2
Cabinet Resolution (W × H) : 384 x 432
Cabinet Dimensions (W × H × D) : 600x337.5x34
Cabinet Surface Area (m²) : 0.2
Weight Per Cabinet (kg/unit) : 5.3
Weight Per Square Meter (kg/m²) : 26.17
Physical Pixel Density (pixels/m²) : 409,600
Flatness Of Cabinet (mm) : ±1.0
Cabinet Material : Die-casting Aluminum
Service Access : Front
OPERATION SPECIFICATIONS
Operating Temperature(℃) : -10℃ to +45℃
Operating Humidity : 0~80%RH
IP Rating Front : IP30
IP Rating Rear : IP30
